Measuring range
10 kΩ… 2 TΩ
( 104….1012Ω)
tolerance: ± 1 x 10n
Measuring voltages
< 200kΩ = 10V
> 200kΩ = 100V
Specifications
| Dimensions: | 200mm x 100mm x 40mm (L x W x H) |
| Weight: | approx. 380g (without batteries) |
| Display: | Alphanumeric display (2 rows x 16 digits), indicator panel 60mm x 15mm |
| PC-Interface: | USB – Interface with small USB Socket
|
| Power supply: | 4 pc. AA cells, 2100mAh. (permanent supervised) operating time approx. 6h with fully charged cells, external with mains adapter 9V DC / 300mA |
| Charging time: | max. 14h |
| Power comsumption: | max. 100mA |
| Auto Switch Off: | approx. 5min after the measurement, when no button pressed |
Scope of delivery TOM-600
- Mains adapter 230V~ / 50Hz – 9V DC / 300mA
- 4 pc. AA Mignon NiMH cells
- 2 pc. teflon isolated measurement strips 1m each, with 4mm banana plugs
- serial pc USB
- software on CD
- manual
Additional scope of delivery TOM-600 ME
- 2 pc. measurement electrodes 2,5 kg according to EOS/ESD-S4.1 and S7.1
- 1 pc. teflon isolated measurement strip 5m instead of 1 pc. teflon isolated measurement strip 1m with 4mm banana plugs
